00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09 223
11 Fieldwork
11.9 Crop receptacle / straw receptacle
67087
11.9 Crop receptacle / straw receptacle
83223
11.9.1 Putting the straw chopper into opera-
tion (swinging the standard spreader to
chopping position)
– Observe the general warnings at the beginning of
the "Fieldwork" chapter.
– Open the right side cover.
– Unhinge belt (1) from bracket (2) and install it on
pulley (3).
– Check belt (5). The belt (5) must make contact
with all pulleys, jockey pulleys and guide rollers.
Provide contact of belt if required.
– Unhinge belt (1) from bracket of jockey pulley (4).
Danger!
Machine components may run on although the
drive has been shut down.
Death or serious injury.
– Never touch any machine parts that are
running on.
– Wait until all machine parts have stopped
moving.
52
19671
1
3
2
53
19672
4
5
1
