13.5.1 Overview of engine
CATERPILLAR C-6.6
– Observe the information provided in the operator's
manual of the engine manufacturer.
– Observe the information provided in the operator's
manual of the engine manufacturer.
85499
13.5.2 Overview of engine
CATERPILLAR 3056 E
– Observe the information provided in the operator's
manual of the engine manufacturer.
1
27295
F
5
1
7
6
3
4
2
Designation
1 Alternator
2 Oil level dipstick
3 Oil filter
4 Oil filler neck
5 Starter
6 Turbocharger
7 Charge air blower
F Direction of travel
2
27296
F
3
2
1
Designation
1 Engine control module
2 Engine number
3 Fuel filter
F Direction of travel
3
29342
F
1
4
3
5
6
2
Designation
1 Alternator
2 Oil filter
3 Engine number
4 Starter
5 Charge air blower
6 Turbocharger
