170 00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09
9 Driving and transportation
9.7 Cab / Operator's platform
67085
– Adjusting the driver's sear forward and backward
- Pull up lever (1).
Slide driver's seat forward or backward.
- Release lever (1).
A clicking sound is heard and lever (1) engages.
The driver's seat cannot be displaced any more.
– Adjusting the back rest inclination
- Lift lever (1).
- Adjust back rest as desired.
- Release lever (1).
The back rest cannot be adjusted any more.
65
19424
1
Danger!
Operating error.
Death or serious injury.
– Strictly comply with instructions and
results.
66
19424
1
Danger!
Operating error.
Death or serious injury.
– Strictly comply with instructions and
results.
