7 Overview of controls
7.2 Cab / Operator's platform
67083
17 Steering wheel
18 Clutch pedal
19 Steering column locking pedal
20 Foot brake pedals
21 Headlights switch
22 Ignition switch
23 Buzzer
24 Gear shift gate with control lever for hydraulic control unit (lift hydraulics)
25 Cutterbar height indicator
26 Cutterbar spring pressure indicator
27 Fore and aft reel adjustment
28 Cutterbar reverser On/Off locking rocker switch
