00 0293 210 2 - BA DOMINATOR 150/140/130 - 12/09 89
5 Prior to initial operation
5.2 Chassis
67081
5.2 Chassis
89352
5.2.1 Removing / installing the wheels
– Observe the general warnings at the beginning of
the Prior to initial operation chapter.
– Jack up the machine.
– Remove / install wheel.
Ensure that large tyres cannot tip over, if neces-
sary use a carriage.
– After fitting the wheel, tighten all wheel nuts /
wheel bolts (1) to the specified tightening torque
as instructed.
79223
5.2.2 Overview of rear axle
Either one or several different types of rear axles are
available.
The part number for identifying the rear axle is pro-
vided on the identification plate of the axle.
Rear axle
00 0770 350 1
1
9617
1
2
27215
