cobas h 232 User Manual

General Product Specifications
183
10 General Product Specifications
10.1 Operating conditions and technical data
Technical data
Temperature range 18-32 °C
Relative humidity 10-85% (no condensation)
Maximum altitude 4300 m
Position Always place the meter on a level, vibration-free surface when
applying the sample to the sample application area of the test
strip. Once the sample has been completely absorbed by the
test strip, you can move the meter.
Measuring range Depends on test parameters
Memory 2000 Patient Test Results
500 QC Test Results
200 IQC Test Results
100 Strip Code Chips
100 QC Code Chips
4000 Patient List entries
5000 Operator List entries
Interface Infrared interface, LED/IRED Class 1
Supported barcodes Code 128, Code 39, Code 93, EAN 13, Interleaved 2/5,
Codabar, GS1 DataBar Limited, QR Code, DataMatrix, PDF417,
Aztec
Battery operation Handheld battery pack
Mains connection Power adapter:
Input: 100-240 V AC (± 10%) / 50-60Hz / 350-150 mA
Output: 12 V DC / 1.25A
Number of tests with fully
charged battery
approx. 10 tests
Safety class III
Automatic power-off Programmable 1 … 60 minutes
Dimensions 244  105  51 mm
Weight approx. 526 g incl. battery pack and scanner

cobas h 232 Specifications

General

Device Type	Point-of-care analyzer
Sample Type	Whole blood, plasma
Measured Parameters	Troponin T, Myoglobin, D-Dimer, NT-proBNP
Connectivity	USB
Intended Use	cardiac markers
Data Management	LIS connectivity
Throughput	Single test
Sample Volume	150 µL
Operating Temperature	15-30 °C
Operating Humidity	10-85% (non-condensing)
Display	Color touchscreen
Measurement Principle	Electrochemiluminescence immunoassay (ECLIA)
