Introduction
29
Test strip
P Test area
This area is evaluated by the meter via the
camera.
Q Sample application area
The sample is applied to this area after
inserting the test strip in the meter.
R Barcode
Assigns the strip to the corresponding
code chip. The barcode is automatically
read by the meter when the strip is
inserted into the test strip guide.
S Code chip
Contains strip lot specific data.
P
Q
S
R
