Using an Internal Modem 7-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Karen Williams Saved by: Integrity Group Saved date: 06/01/00 3:44 PM
Part Number: 168894-001 File name: CH07.doc
Using the Modem While Traveling
Internationally
Using a Country-Specific Modem Adapter
Telephone jacks vary by country.
The modem cable included with the computer plugs directly into
an RJ-11 telephone jack.
To plug the modem cable into a different type of telephone jack,
you must use a country-specific modem cable adapter. If the
computer is a modem model and RJ-11 telephone jacks are not
standard in your region, a country-specific modem cable adapter
for the telephone jacks in your region is included with the
computer.
To obtain the country-specific adapters required for your
itinerary, refer to Appendix A to contact a Compaq authorized
dealer, reseller, or service provider.
To connect the modem using a country-specific modem
adapter
—
IMPORTANT:
The modem cable, which has a 6-pin RJ-11 connector at
each end, may contain noise suppression circuitry
1
. This circuitry
prevents interference with TV and radio reception. Orient a cable
with this circuitry as shown in the following illustration.
1. Plug the modem cable into the RJ-11 jack on the computer
2
22
2
.
2. Plug the country-specific modem adapter into the telephone
jack
3
.
3. Plug the modem cable into the country-specific modem
adapter
4
.
