Compaq Armada M700 Series User Manual

9-4 Upgrading Memory
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Karen Williams Saved by: Karen Williams Saved date: 05/29/00 5:29 PM
Part Number: 168893-001 File name: CH09.doc
Inserting a Memory Expansion Board
All memory expansion boards supported by the computer
■
Can be used in either of the two memory expansion slots.
■
Are keyed (notched) to ensure correct positioning.
1. Slide the memory expansion board into an empty memory
expansion slot at a 45-degree angle
1
until it is seated.
2. Push the memory expansion board down until the retention
clips
2
snap into place.
Replacing the Keyboard
Line up the bottom edge of the keyboard and fold it back into
place
1
. Then snap the four tabs at the top of the keyboard
2
.

Compaq Armada M700 Series Specifications

General

Brand	Compaq
Model	Armada M700 Series
Category	Laptop
Language	English
