Using Drives 5-3
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Karen Williams Saved by: Karen Williams Saved date: 05/31/00 10:00 AM
Part Number: 168893-001 File name: CH05.doc
Hard Drives
!
WARNING:
To reduce the risk of personal injury from hot surfaces,
allow the internal system components to cool before touching them.
Removing a Hard Drive from the Hard Drive Bay
1. Save your work, then shut down the computer.
2. Push down the hard drive tab on the front of the hard drive
until it snaps away from the front of the computer
1
.
3. Lift up the front cover of the drive 90 degrees to create a
handle
2
and pull the hard drive out of the hard drive bay.
