10-2 Using Audio and Video Features
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Karen Williams Saved by: Karen Williams Saved date: 05/29/00 5:31 PM
Part Number: 168893-001 File name: CH10.doc
Connecting an External Audio Device
CAUTION:
To prevent possible damage to an external device, do not
plug a single-sound channel (monaural) connector into the stereo
speaker/headphone jack.
Selecting an Audio Connector
To Connect This Device Use This Jack
Stereo speakers, headphones,
headset, or audio/visual device
such as a television or VCR
1
Stereo speaker/headphone jack
Single sound channel
microphone
2
Microphone jack
Connecting a Device to the Microphone Jack
The microphone jack supports a single sound channel (monaural)
microphone with a 3.5-mm plug. A powered, single sound
channel, electret condenser microphone is recommended.
â–
A stereo microphone records left-channel sound on both
channels.
â–
A dynamic microphone does not achieve the recommended
sensitivity.
When an external microphone is connected to the computer, the
computer microphone is disabled.
