LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Serial-based Remote Product Management MN-LPOD
5–12
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Attenuation
ATT=
5 bytes
Command or Query.
Sets or returns attenuation level in the form xx.xx, where:
xx.xx=00.00 to 20.00, in dB, in 0.25 dB steps as factory default.
Default value: 10.00
Example: <1/ATT=12.25’cr’
>0001/ATT=’cr’’lf’
ATT=
ATT?
ATT*
ATT?
ATT=xx.xx
(See Description of
Arguments)
Auxiliary Mute
Enable
AUX=
1 byte
Command or Query.
Sets or returns the auxiliary mute mode in the form x, where:
0=Disabled (default value)
1=Enabled
Notes:
1. When enabled, the mute control input on the remote com connector must be grounded to UN-MUTE the unit.
Otherwise, the unit will be muted, and if a mute query is given (MUT?) the response will be MUT=2 to indicate
a hardware controlled mute is present.
2. Aux mute is one of several hardware mute states that can cause a MUT=2 to be reported. See the MUT
command for more info on mute states.
3. Auxiliary mute supersedes the user mute state so if the command MUT=1 is sent, then AUX=1 is sent, and the
user shorts Pin K to Pin S on the discrete control connector then the RF mute will be disabled (MUT=0).
Example (AUX Mute Enabled): AUX=1’cr’
AUX=
AUX?
AUX*
AUX?
AUX=x
(See Description of
Arguments)
Clear All Stored
Alarms
E
CAA=
None
Command only.
Instructs the LPOD to clear all Stored Alarms. This command takes no arguments.
Example: <1/CAA=’cr’
>0001/CAA=’cr’’lf’
CAA=
CAA*
N/A
N/A
Clear All Stored
Events
CAE=
None
Command only.
Instructs the LPOD to clear all Stored Events. This command takes no arguments.
Example: <1/CAE=’cr’
>0001/CAE=’cr’’lf’
CAE=
CAE*
N/A
N/A
