RTF - Probe Control Board
The probe control board (RTF) recognizes different probe types and
switches between the Probe Connectors (3 DLP-Connectors, 1 CW-
Connector) as required. The board contains:
 One optional CW-Probe Connector
 Three 408 pin Probe-Connectors
 One 408pin Dummy-Probe Connector
 Probe Select Relays
 Probe Recognition
RSE - Pencil Probe Board (optional)
CW scanning is optional on the Voluson E10. This adapter board is for
the connection of CW pencil probes is required for CW-Option.
RFM - (RF-Interface & Beamformer) FE Mainboard
The FrontEnd Mainboard supports Tx/Rx for 128 channels only.
RFM Board - Interface FPGA
The interface FPGA on the RFM board provides the following
functions:
 DMA logic
 Beamformer Interface
 RTF Control Interface
 RTF FPGA Control Interface
RFM Board - Processing FPGA
The processing FPGA on the RFM board provides the following
functions:
 Ultrasound Data Pre-Processing
 System Control
 Motor Control
RSX - (Beamformer Receiver/Transmitter) Extension Board
Subset (for RFM) that is required to extend to 192 or 256 channels. All
To extend to 192 or 256
channels, the RSX-
(Beamformer
Receiver/Transmitter)
Extension board is
required.
