Web Operations 146
Video monitoring screen Figure 5-24
Table 5-8 Video monitoring window parameters description
No.
Parameter
Description
1–4
Device information
Displays the IP address, channel number, bit rate, and stream
type (M represents main stream, S represents sub stream).
5
Zoom
Click this icon and then hold down the left mouse button to
select the area you want to enlarge. The area is enlarged after
the left mouse button is released. Click this icon again or
right-click on the window to exit.
6
Record
Click this icon to start recording. Click it again to stop recording.
The recorded files default storage path is C:\RecordDownload.
You can modify this path if needed. For details, see "5.3.1.2.4
Configuring Save Path."
7
Snapshot
Click this icon to start taking snapshot.
The snapshots default storage path is C:\PictureDownload. You
can modify this path if needed. For details, see "5.3.1.2.4
Configuring Save Path."
8
Audio
Turns on/off audio. If audio function is not enabled in the
encode settings, there will not be sound in monitoring.
9
Close
Close the live view in the window.
Bit rate
The system supports switching between main stream and sub stream in real-time monitoring
window. See Figure 5-25. For details about bit rate settings, see "5.3.1.2 Configuring Encode."
Bit rate Figure 5-25
