Local Configurations 38
Indicates positioning module connection failed.
Indicates positioning module connection succeeded.
Displays the DSS registration status of the Device. For details about DSS
registration, see "4.3.3.3 Configuring Auto Register Settings."
Indicates DSS registration failed.
Indicates DSS registration succeeded.
4.2.1.1 Preview
You can view the information such as time, channel name, GPS, and recording and alarm
status in the channel view. For the meaning of recording and alarm icons, see Table 4-7.
Table 4-7 Recording and alarm icons
This icon displays when the video is being recorded.
This icon displays when the motion detection occurs.
This icon displays when the video loss is detected.
4.2.1.2 Live View Control bar
When you move the pointer to a channel window, the live view control bar is displayed. See
Figure 4-20. If there is not operation for six seconds after the control bar is displayed, the
control bar hides automatically.
Live View Control bar Figure 4-20
Click , the icon switches to . Hold down the left mouse button to select the area
that you want to enlarge. The area is enlarged after the left mouse button is released. You
can also drag the enlarged area. Right-click on the screen to exit.
Click , the REMOTE interface is displayed. You can replace the current remote device
in the channel window. Only the Channel 9 to Channel 12 supports this function.
Click to turn the image display upside down, left and right.
4.2.1.3 Shortcut Menu
Right-click on the live view screen, the shortcut menu is displayed. See Figure 4-21.
