Dahua MCVR6204 User Manual

Local Configurations 48
 Click Del Preset to delete the preset in tours. This operation can be repeated to
delete more presets. Some protocols do not support deleting.
 Click Del Tour to delete the tour.
4.2.2.3.3 Configuring Patterns
The PTZ camera repeats movement according to the configured operations. The operation
records include the information such as the manual operations and focus adjustment.
On the PTZ control panel, click Set. Step 1
The PTZ function settings interface is displayed.
Click the Pattern tab. Step 2
The Pattern interface is displayed, see Figure 4-32.
Pattern Figure 4-32
In the Pattern box, enter the value for pattern. Step 3
Click Start. Step 4
The PTZ control panel is displayed.
You can perform the operations such as directions movement, zoom and focus Step 5
adjustment.
On the PTZ control panel, click Set > Pattern > End. Step 6
4.2.2.3.4 Configuring Borders
The PTZ camera automatically scans the configured left border and right border after
configuration.
On the PTZ control panel, use the direction buttons to set the left border, and then click Step 1
Set.
The PTZ function settings interface is displayed.
Click the Border tab. Step 2
The Border interface is displayed. See Figure 4-33.
