Daikin Myzone 3 - A;C Unit Control and Modulating Zone Control with Wired Isense Zone Temperature Controllers (Wi-Fi Optional)

23
Myzone Wiring Layout
A/C Unit Control and Modulating Zone Control with Wired
iSense Zone Temperature Controllers (Wi-Fi Optional)
240V/24V
A/C Unit
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599)
Twin-Shielded
Cable
Myzone 3 CPU
(3205598)
Note:
Due to space restrictions, not all iSense
zone temperature sensors can be shown.
240V/24V
RJ45 Cable
(3205601)
RJ12 Cable
(1609219)
Nexus Tablet
(205295)
Myzone 3 Network Extension
Module (3205100)
