Auto Fan
Unity Capacity
Fan Airflow
[KW]
[L/S]
14
1020
Variable Speed Fan
2- Speed Fan
3- Speed Fan
Fan Auto Config
Enable Fan Auto Control
Capacities
Select Fan Type
BackPreviousNext
72
Fan Auto
Configuration
Touch here to enable Fan Auto
control and to proceed with Fan
Auto set up
Select the correct fan
speed type for the system
installed. Refer to A/C unit
manufacturer manual
Touch here to configure the
zone areas (see page 68)
It is recommended to use
3 speed fan setting for
best use of the "Auto Fan"
Function
Only Available on certain
A/C unit makes.
Touch here to set the A/C Unit
capacity for this system. The
capacity selection will provide an
approximate airflow capacity for
the A/C Unit.
Touch here to fine tune the airflow
capacity. You can set the exact
airflow in litres per second. This
is available from the A/C Unit
manufacturer.
To Next Page
