Back
Zone Setup
Kitchen Wireless
Passage Const 1
Family Touch
Master Bed Wired
Jon Bed Opn/Clsd
Study iSense
Up Down
65
Zone Set Up
Touch here to go to the
home screen
Indicates this zone temperature is
controlled by a wireless sensor
Indicates this zone temperature is
controlled via the sensor in a touch
screen. Touch here to change.
Indicates this zone is set up for
temperature control via a wired
sensor. Touch here to change.
Indicates this zone has been set
up for Open/Close control only
If the zone has been named,
it will appear here, if no
name has been assigned,
it will show the zone
number e.g. Zone 3.
Indicates this zone is designated
to be the first electronic
constant zone.
Indicates this zone is set up for
temperature control via an
iSense controller
Once the number of zones and constants
have been configured, each zone needs
to be assigned a control configuration.
Two manual control options and five
climate control options are available.
