Daikin Myzone 3 - Myzone Wiring Connections to Universal Control Module

48
Gas Heating Options
• Gas Heating thermostat only
• 1 Stage Gas Heat + 1 x Fan Speed
• 1 Stage Gas Heat + 1 Stage Cool + 1 x Fan Speed
• 2 Stage Gas Heat + 1 Stage Cool + 1 x Fan Speed
• 2 Stage Gas Heat + 2 Stage Cool + 1 x Fan Speed
Reverse Cycle Options
• 1 Stage R/C + 1 x Fan Speed
• 1 Stage R/C + 3 x Fan Speed
• 1 Stage R/C + Aux Heating + 1 x Fan Speed
• 2 Stage R/C + Aux Heating + 1 x Fan Speed
64. Unit make:
65. Units that accept 24V
control signals
Myzone Wiring
Connections to
Universal Control
Module
Connection
1. Connect cables as shown on the wiring diagram for the
respective option (24V maximum).
2. Configure the correct system type on the touch screen.
3. Configure the Run on timer, anti-cycle timer, 2nd stage oset,
2nd stage delay and fan control on the touch screen,
as applicable.
4. Test for correct operation.
