Myzone 3 12:00PM 01 Jan 2021
SYSTEM ZONES AC UNIT OPTIONS
Area to be Covered by Const.
Area [m2]
0
Constant Control by Area
Const Control
Unit Auto Off
Use In-duct Energy
Auto Mode Dead Band 1.50
AC Unit Make
Auto Detect AC Unit
Controlling Sensor Zones
Fan Auto
Constant Control
Enable
90
A/C Unit
Configuration
Constant Control
Advanced constant control
will use area (m) in lieu of %
of total zones open to control
the constant zone or bypass
damper. NOTE: all room areas
must be entered accurately for
this to function correctly.
If the zone areas total 50m
and the equivalent of 25m
of zones are open, with a
minimum area to be covered
of 35m, then the constant or
bypass will open in % to the
equivalent of 10m.
E.g.
Zone 1 Area = 13m @20% Open
Zone 2 Area = 12m @30% Open
Constant or Bypass = 10m @ 15% Open
