Danfoss VLT AutomationDrive FC 300 Design Guide

Code
number AHF005
IP00
IP20
Code
number AHF010
IP00
IP20
Filter
current
rating
Typical
motor
VLT model/
current
ratings
Losses
Acoustic
noise
Frame size
AHF005 AHF010
[A]
hp
[kW]
hp
[kW]
[A] [W] [W] [dBA] AHF005 AHF010
2x130B3157
2x130B3156
2x130B3155
2x130B3154
650 450
[315]
P475
[P355]
647 2812 1904 <80
130B3133+130B3134
130B2871+130B2872
130B3092+130B3093
130B2819+130B2855
685 475
[355]
P550
[P400]
684 2798 2080 <80
2x130B3134
2x130B2872
2x130B3093
2x130B2855
762 550
[400]
P600
[P450]
779 3020 2350 <80
130B3134+130B3135
130B2872+130B3135
130B3093+130B3094
130B2855+130B2856
861 600
[450]
P650
[P500]
857 3362 2717 <80
2x130B3135
2x130B2873
2x130B3094
2x130B2856
960 650
[500]
P750
[P560]
964 3704 3084 <80
3x130B3134
3x130B2872
3x130B3093
3x130B2855
1140 750
[560]
P850
[P630]
1090 4530 3525 <80
2x130B3134+130B3135
2x130B2872+130B2873
2x130B3093+130B3094
2x130B2855+130B2856
1240 850
[630]
P950
[P710]
1227 4872 3892 <80
3x130B3135
3x130B2873
3x130B3094
3x130B2856
1440 950
[710]
P1075
[P800]
1422 5556 4626 <80
2x130B3134+2x130B3135
2x130B2872+2x130B2873
2x130B3093+2x130B3094
2x130B2855+2x130B2856
1722 1075
[800]
P1M0 1675 6724 5434 <80
Table 5.14 Advanced Harmonic Filters, 380–415 V, 60 Hz, E- and F-frames
Code
number
AHF005
IP00
IP20
Code
number
AHF010
IP00
IP20
Filter
current
rating
Typical
motor
VLT model and
current ratings
Losses
Acoustic
noise
Frame size
AHF005 AHF010
[A] [HP] [HP] [A] [W] [W] [dBA] AHF005 AHF010
130B1799
130B1764
130B1782
130B1496
183 150 N110 183 1080 743 <75 X6 X6
130B1900
130B1765
130B1783
130B1497
231 200 N132 231 1194 864 <75 X7 X7
130B2200
130B1766
130B1784
130B1498
291 250 N160 291 1288 905 <75 X8 X7
130B2257
130B1768
130B1785
130B1499
355 300 N200 348 1406 952 <75 X8 X7
130B3168
130B3167
130B3166
130B3165
380 Used for paralleling at 355 kW 1510 1175 <77 X8 X7
130B2259
130B1769
130B1786
130B1751
436 350 N250 436 1852 1542 <77 X8 X8
130B1900+
130B2200
130B1765+
130B1766
130B1783+
130B1784
130B1497+
130B1498
522 450 N315 531 2482 1769 <80
Table 5.15 Advanced Harmonic Filters 440–480 V, 60 Hz, D-frame
How to Order
Design Guide
100 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
