1-00 Configuration Mode [1] Speed closed-loop
1-01 Motor Control Principle [3] Flux with feedback
1-10 Motor Construction [1] PM, non-salient SPM
1-24 Motor Current Nameplate
1-25 Motor Nominal Speed Nameplate
1-26 Motor Cont. Rated Torque Nameplate
AMA is not possible on PM motors
1-30 Stator Resistance (Rs) Motor data sheet
30-80 d-axis inductance (Ld) Motor data sheet (mH)
1-39 Motor Poles Motor data sheet
1-40 Back EMF at 1000 RPM Motor data sheet
1-41 Motor Angle Offset Motor data sheet (usually zero)
17-50 Poles Resolver data sheet
17-51 Input Voltage Resolver data sheet
17-52 Input Frequency Resolver data sheet
17-53 Transformation Ratio Resolver data sheet
17-59 Resolver Interface [1] Enabled
Table 9.4 Parameters to be Adjusted
9.5 Relay Option MCB 105
The MCB 105 includes three pieces of SPDT contacts and must be fitted into option slot B.
Electrical Data
Max terminal load (AC-1)
1)
(Resistive load) 240 V AC 2 A
Max terminal load (AC-15)
1)
(Inductive load @ cosφ 0.4) 240 V AC 0.2 A
Max terminal load (DC-1)
1)
(Resistive load) 24 V DC 1 A
Max terminal load (DC-13)
1)
(Inductive load) 24 V DC 0.1 A
Min terminal load (DC) 5 V 10 mA
Max switching rate at rated load/min load 6 min
-1
/20
-1
1)
IEC 947 part 4 and 5
When the relay option kit is ordered separately, the kit includes:
•
Relay Module MCB 105
•
Enlarged LCP fixture and enlarged terminal cover
•
Label for covering access to switches S201 (A53), S202 (A54) and S801
•
Cable strips for fastening cables to relay module
Options and Accessories Design Guide
256 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
