Danfoss VLT AutomationDrive FC 300 Design Guide

Frame size Bussmann PN Rating Alternative fuses
F8-F13 LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element,
Time Delay, 6 A
Table 7.55 Control Transformer Fuse
Frame size Bussmann PN Rating
F8-F13 GMC-800 MA 800 mA, 250 V
Table 7.56 NAMUR Fuse
Frame size
Bussmann PN Rating Alternative fuses
F8-F13 LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 7.57 Safety Relay Coil Fuse with Pilz Relay
Frame
size
Power & Voltage Type
Default breaker settings
Trip level [A] Time [s]
F3
P450 380–500 V & P630-P710
525–690 V
Merlin Gerin
NPJF36120U31AABSCYP 1200 0.5
F3
P500-P630 380–500 V & P800
525–690 V
Merlin Gerin
NRJF36200U31AABSCYP 2000 0.5
F4
P710 380–500 V & P900-P1M2
525–690 V
Merlin Gerin
NRJF36200U31AABSCYP 2000 0.5
F4 P800 380–500 V
Merlin Gerin
NRJF36250U31AABSCYP 2500 0.5
Table 7.58 F-frame Circuit Breakers
7.3 Disconnectors and Contactors
7.3.1 Line Power Disconnects - Frame Sizes E and F
Frame size Power Type
380–500 V
D5h/D6h N55K–N132 ABB OT400U03
D7h/D8h N160–N315 ABB OT600U03
E1/E2 P250 ABB OETL-NF600A
E1/E2 P315–P400 ABB OETL-NF800A
F3 P450 Merlin Gerin NPJF36000S12AAYP
F3 P500–P630 Merlin Gerin NRKF36000S20AAYP
F4 P710–P800 Merlin Gerin NRKF36000S20AAYP
525–690 V
D5h/D6h N90K–N132 ABB OT400U03
D7h/D8h N160–N250 ABB OT600U03
E1/E2 P355–P560 ABB OETL-NF600A
F3 P630–P710 Merlin Gerin NPJF36000S12AAYP
F3 P800 Merlin Gerin NRKF36000S20AAYP
F4 P900–P1M2 Merlin Gerin NRKF36000S20AAYP
Table 7.59 Line Power Disconnects, 6-Pulse Adjustable Frequency Drives
Electrical Installation Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 217
7 7
