Danfoss VLT AutomationDrive FC 300 Design Guide

7.3.2 Line Power Disconnects, 12-Pulse
Frame size Power Type
380–500 V
F9 P250 ABB OETL-NF600A
F9 P315 ABB OETL-NF600A
F9 P355 ABB OETL-NF600A
F9 P400 ABB OETL-NF600A
F11 P450 ABB OETL-NF800A
F11 P500 ABB OETL-NF800A
F11 P560 ABB OETL-NF800A
F11 P630 ABB OT800U21
F13 P710 Merlin Gerin NPJF36000S12AAYP
F13 P800 Merlin Gerin NPJF36000S12AAYP
525–690 V
F9 P355 ABB OT400U12-121
F9 P400 ABB OT400U12-121
F9 P500 ABB OT400U12-121
F9 P560 ABB OT400U12-121
F11 P630 ABB OETL-NF600A
F11 P710 ABB OETL-NF600A
F11 P800 ABB OT800U21
F13 P900 ABB OT800U21
F13 P1M0 Merlin Gerin NPJF36000S12AAYP
F13 P1M2 Merlin Gerin NPJF36000S12AAYP
Table 7.60 Line Power Disconnects, 12-Pulse Adjustable Frequency Drives
7.3.3
Line Power Contactors
Frame size Power & Voltage Contactor
D6h
N90K-N132 380–500 V GE CK95CE311N
N110-N160 380–480 V GE CK95BE311N
N55-N132 525–690 V GE CK95CE311N
N75-N160 525–690 V GE CK95BE311N
D8h
N160-N250 380–500 V
GE CK11CE311N
N200-N315 380–480 V
N160-N315 525–690 V
N200-N400 525–690 V
Table 7.61 D-frame Contactors
Frame size Power & Voltage Contactor
F3 P450-P500 380–500 V & P630-P800 525–690 V Eaton XTCE650N22A
F3 P560 380–500 V Eaton XTCE820N22A
F3 P630 380–500 V Eaton XTCEC14P22B
F4 P900 525–690 V Eaton XTCE820N22A
F4 P710-P800 380–500 V & P1M2 525–690 V Eaton XTCEC14P22B
Table 7.62 F-frame Contactors
Electrical Installation
Design Guide
218 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
