Danfoss VLT AutomationDrive FC 300 Design Guide

9.2.2 Digital Inputs - Terminal X30/1-4
Digital Input
Number of digital inputs 4 (6)
Terminal number 18, 19, 27, 29, 32, 33
Logic PNP or NPN
Voltage level 0–24 V DC
Voltage level, logic 0' PNP (GND=0 V) <5 V DC
Voltage level, logic 1' PNP (GND=0 V) >10 V DC
Voltage level, logic '0' NPN (GND=24 V) <14 V DC
Voltage level, logic '1' NPN (GND=24 V) >19 V DC
Maximum voltage on input 28 V continuous
Pulse frequency ranges 0–110 kHz
Duty cycle, min. pulse width 4.5 ms
Input impedance >2 kΩ
9.2.3 Analog Inputs - Terminal X30/11, 12
Analog Input
Number of analog inputs 2
Terminal number 53, 54, X30.11, X30.12
Modes Voltage
Voltage level -10 V to +10 V
Input impedance >10 kΩ
Max. voltage 20 V
Resolution for analog inputs 10 bit (+ sign)
Accuracy of analog inputs Max. error 0.5% of full scale
Bandwidth FC 302: 100 Hz
9.2.4 Digital Outputs - Terminal X30/6, 7
Digital Output
Number of digital outputs 2
Terminal number X30.6, X30.7
Voltage level at digital/frequency output 0–24 V
Max. output current 40 mA
Max. load ≥ 600 Ω
Max. capacitive load <10 nF
Minimum output frequency 0 Hz
Maximum output frequency ≤32 kHz
Accuracy of frequency output Max. error: 0.1% of full scale
Options and Accessories Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 251
