Danfoss VLT AutomationDrive FC 300 Design Guide

525 V, 50 Hz 575 V, 60 Hz 690 V, 50 Hz Frame size Filter ordering number
[kW] [A] [HP] [A] [kW] [A] IP00 IP23
45 76 60 73 55 73 D1h/D3h/D5h/D6h 130B4116 130B4117
55 90 75 86 75 86 D1h/D3h/D5h/D6h 130B4118 130B4119
75 113 100 108 90 108 D1h/D3h/D5h/D6h 130B4118 130B4119
90 137 125 131 110 131 D1h/D3h/D5h/D6h
130B4121 130B4124
110 162 150 155 132 155 D1h/D3h/D5h/D6h
132 201 200 192 160 192 D2h/D4h, D7h/D8h
130B4125 130B4126
160 253 250 242 200 242 D2h/D4h, D7h/D8h
200 303 300 290 250 290 D2h/D4h, D7h/D8h
130B4129 130B4151
250 360 350 344 315 344 D2h/D4h, D7h/D8h, F8/F9
350 344 355 380 F8/F9
130B4152 130B4153
315 429 400 400 400 410 F8/F9
400 410 E1/E2, F8/F9
130B4154 130B4155355 470 450 450 450 450 E1/E2, F8/F9
400 523 500 500 500 500 E1/E2, F8/F9
450 596 600 570 560 570 E1/E2, F8/F9
130B4156 130B4157
500 630 650 630 630 630 E1/E2, F8/F9
500 659 630 630 F1/F3, F10/F11 2X130B4129 2X130B4151
650 630 F1/F3, F10/F11
2X130B4152 2X130B4153
560 763 750 730 710 730 F1/F3, F10/F11
670 889 950 850 800 850 F1/F3, F10/F11
2X130B4154 2X130B4155
750 988 1050 945 900 945 F1/F3, F10/F11
750 988 1050 945 900 945 F2/F4, F12/F13
3X130B4152 3X130B4153
850 1108 1150 1060 1000 1060 F2/F4, F12/F13
1000 1317 1350 1260 1200 1260 F2/F4, F12/F13 3X130B4154 3X130B4155
Table 5.22 Sine-Wave Filter Modules 525–690 V
NOTICE!
When using sine-wave filters, ensure that the switching frequency complies with filter specifications in 14-01 Switching
Frequency.
See also Advanced Harmonic Filters Design Guide.
How to Order Design Guide
106 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
55
