Figure 6.6 Recommended Lifting Method, Frame Size F8
NOTICE!
The pedestal is packaged separately and included in the
shipment. Mount the adjustable frequency drive on the
pedestal in its final location. The pedestal allows proper
airflow and cooling to the adjustable frequency drive.
See chapter 6.2.13 Pedestal Installation of F-frames.
Mechanical Installation Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 111
