GLCP
Graphical local control panel (LCP102)
Hiperface
®
Hiperface
®
is a registered trademark by Stegmann.
Initializing
If initialization is carried out (14-22 Operation Mode), the
programmable parameters of the adjustable frequency
drive return to their default settings.
Intermittent Duty Cycle
An intermittent duty rating refers to a sequence of duty
cycles. Each cycle consists of an on-load and an off-load
period. The operation can be either periodic duty or non-
periodic duty.
LCP
The local control panel (LCP) makes up a complete
interface for control and programming of the adjustable
frequency drive. The LCP is detachable and can be
installed up to 10 ft [3 m] from the adjustable frequency
drive, in a front panel with the installation kit option.
The LCP is available in two versions:
•
Numerical LCP101 (NLCP)
•
Graphical LCP102 (GLCP)
lsb
Least significant bit.
MCM
Short for mille circular mil, an American measuring unit for
cable cross-section. 1 MCM ≡ 0.5067 mm
2
.
msb
Most significant bit.
NLCP
Numerical local control panel LCP101.
Online/Offline Parameters
Changes to online parameters are activated immediately
after the data value is changed. Changes to offline
parameters are not activated until [OK] is entered on the
LCP.
PID Controller
The PID controller maintains the desired speed, pressure
and temperature by adjusting the output frequency to
match the varying load.
PCD
Process Data.
Pulse input/incremental encoder
An external digital sensor used for feedback information of
motor speed and direction. Encoders are used for high-
speed accuracy feedback and in high dynamic applications.
The encoder connection is either via terminal 32 or
encoder option MCB 102.
RCD
Residual Current Device. A device that disconnects a circuit
in case of an imbalance between an energized conductor
and ground. Also known as a ground fault circuit
interrupter (GFCI).
Set-up
Parameter settings can be saved in four set-ups. Change
between the four parameter set-ups and edit one set-up,
while another set-up is active.
SFAVM
Switching pattern called Stator Flux oriented Asynchronous
Vector Modulation (14-00 Switching Pattern).
Slip Compensation
The adjustable frequency drive compensates for the motor
slip by giving the frequency a supplement that follows the
measured motor load, keeping the motor speed almost
constant.
Smart Logic Control (SLC)
The SLC is a sequence of user-defined actions executed
when the associated user-defined events are evaluated as
true by the SLC.
STW
Status word.
Thermistor:
A temperature-dependent resistor placed where the
temperature is monitored (adjustable frequency drive or
motor).
How to Read this Design Gui...
Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 13
