Danfoss VLT AutomationDrive FC 300 Design Guide

FC 302 [kW] Drive internal Bussmann PN Rating Alternate Siba PN
450 170M8611 1100 A, 1000 V 20 781 32.1000
500 170M8611 1100 A, 1000 V 20 781 32.1000
560 170M6467 1400 A, 700 V 20 681 32.1400
630 170M6467 1400 A, 700 V 20 681 32.1400
710 170M8611 1100 A, 1000 V 20 781 32.1000
800 170M6467 1400 A, 700 V 20 681 32.1400
Table 7.34 380–480/500 V, Frame Size F, Inverter Module DC Link Fuses
VLT© Model Bussmann PN Siba PN Ferraz-Shawmut European PN Ferraz-Shawmut North American PN
N55k T7 170M2616 20 610 31.160 6.9URD30D08A0160 A070URD30KI0160
N75k T7 170M2619 20 610 31.315 6.9URD31D08A0315 A070URD31KI0315
N90k T7 170M2619 20 610 31.315 6.9URD31D08A0315 A070URD31KI0315
N110 T7 170M2619 20 610 31.315 6.9URD31D08A0315 A070URD31KI0315
N132 T7 170M2619 20 610 31.315 6.9URD31D08A0315 A070URD31KI0315
N160 T7 170M4015 20 620 31.550 6.9URD32D08A0550 A070URD32KI0550
N200 T7 170M4015 20 620 31.550 6.9URD32D08A0550 A070URD32KI0550
N250 T7 170M4015 20 620 31.550 6.9URD32D08A0550 A070URD32KI0550
N315 T7 170M4015 20 620 31.550 6.9URD32D08A0550 A070URD32KI0550
Table 7.35 Fuse Options for 525–690 V, Frame Size D
NOTICE!
For UL compliance, the Bussmann 170M series fuses must be used for units supplied without a contactor-only option.
For units supplied with a contactor-only option, see Table 7.28 for SCCR ratings and UL fuse criteria.
FC 302 [kW] Recommended drive
external fuse
Bussmann PN
Rating Drive internal
option
Bussmann PN
Alternate external
Siba PN
Alternate external
Ferraz-Shawmut PN
355 170M4017 700 A, 700 V 170M4017 20 610 32.700 6.9URD31D08A0700
400 170M4017 700 A, 700 V 170M4017 20 610 32.700 6.9URD31D08A0700
500 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
560 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
Table 7.36 525–690 V, Frame Size E, Line Fuse Options for UL Compliance
FC 302 [kW] Recommended drive
external fuse
Bussmann PN
Rating Drive internal option
Bussmann PN
Alternate Siba PN
630 170M7081 1600 A, 700 V 170M7082 20 695 32.1600
710 170M7081 1600 A, 700 V 170M7082 20 695 32.1600
800 170M7081 1600 A, 700 V 170M7082 20 695 32.1600
900 170M7081 1600 A, 700 V 170M7082 20 695 32.1600
1000 170M7082 2000 A, 700 V 170M7082 20 695 32.2000
1200 170M7083 2500 A, 700 V 170M7083 20 695 32.2500
Table 7.37 525–690 V, Frame Size F, Line Fuse Options for UL Compliance
Electrical Installation
Design Guide
212 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
