Size/Type Bussmann PN Rating Alternative fuses
2.5–4.0 A Fuse
P450-P800, 380–500 V LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual
Element, Time Delay, 6 A
P630-P1M2, 525–690 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
4.0–6.3 A Fuse
P450-P800, 380–500 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
P630-P1M2, 525–690 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
6.3–10 A Fuse
P450-P800, 380–500 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
P630-P1M2, 525–690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
10–16 A Fuse
P450-P800, 380–500 V LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual
Element, Time Delay, 25 A
P630-P1M2, 525–690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
Table 7.42 Manual Motor Controller Fuses
Frame Size Bussmann PN Rating Alternative fuses
F LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element, Time Delay, 30 A
Table 7.43 30 A Fuse Protected Terminal Fuse
Frame size
Bussmann PN Rating Alternative fuses
F LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element, Time Delay, 6 A
Table 7.44 Control Transformer Fuse
Frame Size
Bussmann PN Rating
F GMC-800 MA 800 mA, 250 V
Table 7.45 NAMUR Fuse
Frame size
Bussmann PN Rating Alternative fuses
F LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 7.46 Safety Relay Coil Fuse with PILZ Relay
Electrical Installation Design Guide
214 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
