Enter/Exit Programming Mode 1D Symbologies
142 Gryphon™ GPS4400
Codabar Set Length 2
This feature specifies one of the bar code lengths for Codabar Length Control-
Codabar Length Control. Length 2 is the maximum label length if in Variable
Length Mode, or the second fixed length if in Fixed Length Mode. The length
includes the bar code’s start, stop, check and data characters. The leng
th
must include at least one data character.
The length can be set from 3 to 50 characters. A setting of 0 specifies to
ignore this length (only one fixed length).
Table 14 provides examples for setting Length 2. See page 241 for detailed
instructions on setting this feature.
Table 14. Codabar Length 2 Setting Examples
STEP ACTION EXAMPLES
1
Desired Setting (and pad
with lead
ing z
eros)
00 Ignore This
Length
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODABAR LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CCBL2
Select Codabar Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start again
at the beginning.
~
CANCEL
DEFAULT
50 = Length 2 is 50 Characters
