References Scanning Features
260
Gryphon™ GPS4400
Multiple Labels Ordering by Code Symbology
This feature Specifies the transmission ordering by symbology type, when
Multiple Labels per Frame is enabled.Up to six symbologies can be selected.
zeros must be added to pad the string to 12 characters if not using all six
symbologies.
The labels are ordered first as specified in the output mask. Labels present
in the volume but
not specified will be transmitted as unspecified symbolo-
gies in random order as allowed by the reading time sequ
ence. For each
label decoded in the volume the reader signals the standard beeper and LED
indications.
To specify the symbology order:
1. Determine the symbologies and order you want to specify.
2. Use Table 40 on page 261 to find the hex values for up to six
symbolo-
gies.
3. Go to page 78 and scan the ENTER/EXIT PROGRAMMING MODE bar code
to enter Programming Mode.
4. Scan the bar code: “SELECT SYMBOLOGIES FOR M
ULTIPLE LABELS
ORDERING”.
5. Scan the appropriate two alphanumeric char
acters from the keypad in
Appendix D, Keypad, that represent the desired character/value in step 2
above.
6. Scan zeros if needed to make a 12-character string.
7. When finished, scan the ENTER/EXIT PROGRAMMING MODE
bar code to
exit Programming Mode.
See Table 39 for some examples of how to set this feature.
Table 39. Multiple Labels Ordering by Code Symbology Examples
STEP ACTION EXAMPLES
1 Desired symbology
Code 39 Data Matrix Code 128 Aztec
2 Hex equivalent from
Table 40
24 0E 0C 4E
3 Scan ENTER/EXIT PROGRAMMING MODE
4
Scan SELECT SYMBOLOGIES FOR MULTIPLE LABELS ORDERING
5
Scan Two Characters From
Appendix D, Keypad
‘2’ and ‘4’ ‘0’ and ‘E’ ‘0’ and ‘C’ ‘4’ and ‘E’
RESULT
0x240E0C4E0000
6 Scan ENTER/EXIT PROGRAMMING MODE
Table 40 on page 261 shows the hex value associated with each symbology.
