Code 93 Set Length 2
This feature specifies one of the bar code lengths for Code 93 Length Control.
Length 2 is the maximum label length if in Variable Length Mode, or the sec-
ond fixed length if in Fixed Length Mode. Length includes the bar code’s
check, data, and full-ASCII shift characters. The length does not include
start/stop characters. The l
ength can be set from 1 to 50 characters. A set-
ting of 0 specifies to ignore this length (only one fixed length).
Table
20 provides examples for setting Length 2. See page 241 for detailed
instructions on sett
ing this feat
ure.
Table 20. CODE 93 Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (Ignore This
Length)
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 93 LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CC9L2
Select Code 93 Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and not
save the entry string. You can then start again at the beginning.
~
CANCEL
DEFAULT
50 = Length 2 is 50 Characters
