Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
118 Class Series 2 Programmer’s Manual
STX KtU Read Unique Serial Number from RFID Tag
(Direct Mode – HF [13.56 MHz] ISO15693 Tag Interface)
This command instructs the RFID device to read the unique serial number data from the
tag and then place that data into a replaceable field. It is expected that the tag
transponder will be within the read / write distance of the RFID programming device;
otherwise, “Void” will be printed in the text or bar code label field(s).

This is a sixteen character alphanumeric value; the replaceable field must have an
adequate length.
Syntax:
<STX>KtUabcc<CR>
a
-
The number of retry attempts, 0-9.
b
-
Reserved. Should be 0.
Where:
cc
-
Field number in which to place the data (must be 01,
02, 03, etc.) matching the order of Label Formatting
command, U.

A 00 value will send the ID to the host with no printing.

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
