Datamax E-Class Mark II Programmer's Manual

Overview
6 Class Series 2 Programmer’s Manual
Configuration
Command
Name Function
<STX>Kf
Set Present Distance
Determines label stop position, head
relative. <STX>f edge sensor relative
equivalent command, older models.
<STX>Kc
Configuration Set
Determines default power-up
configuration.
<STX>F
Send Form Feed
Sets the stop position of the printed
label.
<STX>M
Set Maximum Label Length
Length to search for next gap or
reflective mark; not used with
continuous media.
<STX>m
Set to Metric Mode
Subsequent measurements interpreted
in metric (most units, mm/10). Label
equivalent command can be used.
<STX>n
Set to Inch Mode
Subsequent measurements interpreted
in inches (most units in/100) label
equivalent command can be used.
<STX>O
Set Start of Print Position
Effect is not on the label immediately
following command since media position
is at Start of Print between labels;
<STX>K default position relative 64
in/100 maximum deviation.
<STX>S
Set Feed Rate Sets blank label movement speed.
<STX>V
Software Switch
Enables optional hardware, cutter, and
present sensor.

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
