Datamax E-Class Mark II Programmer's Manual

Appendix F – Bar Code Summary Data
Class Series 2 Programmer’s Manual 201
203 DPI Resolutions 300 DPI Resolutions 400 DPI Resolutions 600 DPI Resolutions
Font
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
K .40 5:2 .40 9:4 .40 10:4 .40 15:6
L 1.30 5:2 1.30 9:4 1.30 10:4 1.30 15:6
M .90 3 .90 4 .90 6 .90 9
N .80 3 .80 4 .80 6 .80 9
O .40 6:3 .40 8:4 .40 12:6 .40 18:9
p .08 N/A .08 N/A .08 N/A .08 N/A
Q 1.40 2 1.40 4 1.40 4 1.40 6
R 1.40 2 1.40 4 1.40 4 1.40 6
S 1.40 2 1.40 3 1.40 4 1.40 6
T .80 1 .80 1 .80 2 .80 3
U/u 1.00 N/A 1.00 N/A 1.00 N/A 1.00 N/A
v .5 1 .5 1 .5 2 .5 3
z N/A N/A N/A N/A N/A N/A N/A N/A
Z/z N/A N/A N/A N/A N/A N/A N/A N/A
W1C/W1c N/A N/A N/A N/A N/A N/A N/A N/A
W1D/W1d N/A N/A N/A N/A N/A N/A N/A N/A
W1F/W1f N/A N/A N/A N/A N/A N/A N/A N/A
W1G/W1g .5 5:2 .5 7:3 .5 9:4 .5 14:6
W1I .40 2 .40 4 .40 4 .40 6
W1J .40 2 .40 4 .40 4 .40 6
W1k N/A 2 N/A 3 N/A 4 N/A 6
W1L 0.80 N/A 0.80 N/A 0.80 N/A 0.80 N/A
W1M/W1m N/A N/A N/A N/A N/A N/A N/A N/A
W1N/ W1n 0.40 6:2 0.40 9:4 0.40 12:4 0.40 18:6
(continued)

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
