Datamax E-Class Mark II Programmer's Manual

Appendix P – ILPC Programming Examples
Class Series 2 Programmer’s Manual 283
Scalable Double-Byte Font Map - KANJI
eee
(Font Code)
Scalable
Font Type
Font
Name
Binary
Addressing
Hex ASCII
Addressing
Code
Pages
U40
Scalable Resident
HG-Gothic-B Kanji
Scalable
EUC, JIS,
SJIS, UC
u40
Scalable Resident
HG-Gothic-B Kanji
Scalable
EUC, JIS,
SJIS, UC
UK1
Scalable Resident
HG-Gothic-E Kanji
Scalable
EUC, JIS,
SJIS
uK1
Scalable Resident
HG-Gothic-E Kanji
Scalable
EUC, JIS,
SJIS
u50 - u5z…
u90 - u9z
Scalable Non-Resident
(download)
User defined
U50 -
U5z...
U90 - U9z
Scalable Non-Resident
(download)
User defined

Not all fonts contain an entire compliment of character codes for a given character map.
Sample Kanji Gothic B DPL file (binary addressing) and the resulting label:
<02>L<CR>
D11<CR>
ySPM<CR>
1911S0003100010P020P015Scalable Kanji Gothic B Available<CR>
1B110000020017001234567890<CR>
yUJS<CR>
1X1100001900010b0392011000020002<CR>
112200002800030JIS CHARACTER’S IN ALL 4 ROTATION’S<CR>
112200002600030Rotation 1<CR>
1911U4002650150P012P012<4D><3F><21><21><21><21><4D><4F><21><21><21><21><4D>
<5F><21><21><21><21><4D><6F><00><00><CR>
112200002400030Rotation 2<CR>
2911U4002600150P012P012<4D><3F><00><00><CR>
2911U4002600205P012P012<4D><4F><00><00><CR>
2911U4002600250P012P012<4D><5F><00><00><CR>
2911U4002600300P012P012<4D><6F><00><00><CR>
112200002200030Rotation 3<CR>
3911U4002330315P012P012<4D><6F><21><21><21><21><4D><5F><21><21><21><21><4D>
<4F><21><21><21><21><4D><3F><00><00><CR>
112200002000030Rotation 4<CR>
4911U4001950165P012P012<4D><3F><00><00><CR>

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
