Scalable Double-Byte Font Map - CHINESE
eee
(Font Code)
Scalable
Font Type
Font
Name
Binary
Addressing
Hex ASCII
Addressing
Code
Pages
UC0
Scalable Resident
Simplified
GB Chinese
GB
uc0
Scalable Resident
Simplified
GB Chinese
GB
U50 -
U5z...
U90 - U9z
Scalable Non-Resident
(download)
Big 5 B5
u50 - u5z…
u90 - u9z
Scalable Non-Resident
(download)
Big 5 B5
U50 -
U5z...
U90 - U9z
Scalable Non-Resident
(download)
User
defined –
u50 - u5z…
u90 - u9z
Scalable Non-Resident
(download)
User
defined –
Sample Simplified GB Chinese DPL file (binary addressing) and resulting label:
<02>L<CR>
D11<CR>
ySPM<CR>
1911S0003100010P020P015Scalable Chinese Available in GB Character Set<CR>
1B110000020017001234567890<CR>
yUGB<CR>
1X1100001900010b0392011000020002<CR>
112200002800030GB CHARACTER’S IN ALL 4 ROTATION’S<CR>
112200002600030Rotation 1<CR>
1911UC002650150P012P012<BD><D0>A1><A1><A1><A1><BD><D1><A1><A1><A1><A1><BD>
<D2><A1><A1>
<A1><A1><BD><D3><00><00><CR>
112200002400030Rotation 2<CR>
2911UC002600150P012P012<BD><D0><00><00><CR>
2911UC002600205P012P012<BD><D1><00><00><CR>
2911UC002600250P012P012<BD><D2><00><00><CR>
2911UC002600300P012P012<BD><D3><00><00><CR>
112200002200030Rotation 3<CR>
3911UC002330315P012P012<BD><D3><A1><A1><A1><A1><BD><D2><A1><A1><A1><A1><BD>
<D1><A1><A1><A1><A1><BD><D0><00><00><CR>
112200002000030Rotation 4<CR>
4911UC001950165P012P012<BD><D0><00><00><CR>

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
