Figure 79. Installing the system battery
Next steps
1 Follow the procedure listed in After working inside your system.
2 Enter the System Setup to conrm that the battery is operating properly.
3 Enter the correct time and date in the System Setup's Time and Date elds.
4 Exit the System Setup.
5 To test the newly installed battery, remove the system from the enclosure, for at least an hour.
6 Reinstall the system into the enclosure, after an hour.
7 Enter the System Setup and if the time and date are still incorrect, see Getting help.
System board
Removing the system board
Prerequisites
CAUTION
: If you are using the Trusted Platform Module (TPM) with an encryption key, you may be prompted to create a
recovery key during program or System Setup. Be sure to create and safely store this recovery key. If you replace this system
board, you must supply the recovery key when you restart your system or program before you can access the encrypted data on
your hard drives.
CAUTION: Do not attempt to remove the TPM plug-in module from the system board. Once the TPM plug-in module is installed,
it is cryptographically bound to that specic system board. Any attempt to remove an installed TPM plug-in module breaks the
cryptographic binding, and it cannot be reinstalled or installed on another system board.
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the following:
a Air shroud
b Internal cooling fan
c Expansion cards, if installed
Installing and removing system components
105
