Installing the front bezel
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Locate and remove the bezel key.
NOTE: The bezel key is part of the bezel package.
Steps
1 Align and insert the bezel tabs into the slots in the system.
2 Press the release latch, and push the bezel toward the system until the bezel locks into place.
3 Lock the bezel.
Figure 18. Installing the front bezel
System feet
Removing the system feet
Prerequisites
NOTE
: It is recommended that you remove the system feet only when you are replacing the system feet with the wheel
assembly.
1 Follow the safety guidelines listed in Safety instructions..
2 Place the system on its side on a at, stable surface.
3 Rotate the system feet inward.
Installing and removing system components
45
