Figure 25. Installing the air shroud
Next steps
1 Install the system cover.
2 Follow the procedure listed in Before working inside your system.
Intrusion switch
Removing the intrusion switch
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Keep the plastic scribe ready.
Steps
1 Disconnect the intrusion switch cable connector from the system board.
NOTE
: Observe the routing of the cable as you remove it from the system. Route the cable properly when you replace it to
prevent the cable from being pinched or crimped.
2 Using the plastic scribe, slide the intrusion switch out of the intrusion switch slot.
Installing and removing system components
53
