Figure 23. Installing the system cover
Next steps
1 Place the system upright on its feet on a at, stable surface.
2 Install the front bezel.
3 Reconnect the peripherals, and connect the system to the electrical outlet.
4 Power on the system and all attached peripherals.
Air shroud
Removing the air shroud
Prerequisites
CAUTION
: Never operate your system with the air shroud removed. The system may get overheated quickly, resulting in
shutdown of the system and loss of data.
1
Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the system cover.
Step
Holding the blue touch points, lift the air shroud out of the system.
Installing and removing system components
51
