M.2 SSD module
Removing the M.2 SSD module
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the air shroud.
4 Remove the BOSS card.
NOTE: The procedure to remove the BOSS card is similar to removing an expansion card.
Steps
1 Using the Phillips #1 screwdriver, remove the screws securing the M.2 SSD module to the BOSS card.
2 Pull the M.2 SSD module to disconnect from the BOSS card connector.
Figure 60. Removing the M.2 SSD module
Next step
Replace the M.2 SSD module.
Installing the M.2 SSD module
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the air shroud.
Installing and removing system components
87
