Dell C1765nf Color Laser User Manual

150 Understanding the Tool Box Menus
Registration Adjustment
Purpose:
To set Color Registration Adjustment (individual yellow, magenta, cyan correction) settings. When Auto
Registration Adjustment is set to On, the printer prints the color registration chart and adjusts the color registration
by using the chart. Color registration adjustment need to be made during the initial setup of the printer or when the
printer is moved to a different location.
Va lu es :
Envelope Available Range:
-3 – +3
Label Available Range:
-3 – +3
Apply New Settings After you complete the settings, click Apply New Settings to apply the changes.
Auto Registration
Adjustment
Off Automatically adjusts color registration.
On Does not automatically adjust color registration.
Auto Correct
*1
Click Start to automatically correct color registration.
Print Color Regi Chart
*1,*2
Click Start to print a color registration chart.
Color Registration
Adjustment 1 (Lateral)
*1
Yellow Available Range:
-5–+5
Specifies lateral (perpendicular to paper feed
direction) color adjustment values individually.
Magenta Available Range:
-5–+5
Cyan Available Range:
-5–+5
Color Registration
Adjustment 2 (Process)
*1
LY(Left Yellow) Available Range:
-5–+5
Specifies process (paper feed direction) color
adjustment values individually.
LM(Left Magenta) Available Range:
-5–+5
LC(Left Cyan) Available Range:
-5–+5
RY(Right Yellow) Available Range:
-5–+5
RM(Right Magenta) Available Range:
-5–+5
RC(Right Cyan) Available Range:
-5–+5
Apply New Settings After you complete the settings, click Apply New Settings to apply the
changes.
*1
This item is available only when Auto Registration Adjustment is set to Off.
*2
The color registration chart prints a lattice pattern of yellow, magenta, and cyan lines. On the chart, find the values on the right side that
are next to the line that is perfectly straight for each of the three colors. If the value for this line is 0, color registration is not needed. If
the value for this line is any value other than 0, specify the adjustment values under Color Registration Adjustment.

Dell C1765nf Color Laser Specifications

General

Print Resolution	600 x 600 dpi
Scan Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Monthly Duty Cycle	30, 000 pages
Input Capacity	150 sheets
ADF Capacity	15 sheets
Functions	Print, Copy, Scan, Fax
Standard Memory	128 MB
Paper Handling Output	100 sheets
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Duplex Printing	Manual
Paper Capacity	150 sheets
Fax Transmission Speed	3 seconds per page
Print Technology	Laser
Media Sizes Supported	A4, Letter, Legal, Executive
First Page Out Time	27 seconds (color)
Maximum Paper Size	Legal (8.5 in x 14 in)
Operating System Compatibility	Windows, Mac OS
