Dell C1765nf Color Laser User Manual

Understanding the Printer Menus 173
Delayed Start
Purpose:
This feature enables you to set a specific time for the fax transmission to start. Once Delayed Start mode is
activated, your printer stores all of the documents to be faxed into its memory and sends them at the specified time.
After faxing in the Delayed Start mode is complete, the data in the memory is cleared.
Va lu es :
NOTE: A maximum of 19 delayed fax jobs can be stored in this printer.
Print from USB Defaults
Layout
Purpose:
To automatically enlarge print documents when you print directly from a USB storage device.
Va lu es :
Tray Settings
Use the Tray Settings menu to set the paper size and type of paper loaded in the Multipurpose Feeder (MPF).
NOTE: Values marked by an asterisk (*) are the factory default menu settings.
MPF
Purpose:
To specify the paper loaded in the MPF.
Va lu es :
21:00*/PM9:00* Specify the fax transmission start time when sending a fax at a specified time.
0:00 - 23:59 /
AM/PM1:00 - 12:59
Auto* Automatically enlarges print documents to fit on the paper.
Off Does not enlarge print documents.
Paper Size A4 (210 x 297 mm)
*1
A5 (148 x 210 mm)
B5 (182 x 257 mm)
Letter (8.5 x 11")
*1
Folio (8.5 x 13")
Legal (8.5 x 14")
Executive (7.25 x 10.5")
Envelope #10 (4.1x9.5")
Monarch Env. (3.9x7.5")
Monarch Env. L (7.5x3.9")

Dell C1765nf Color Laser Specifications

General

Print Resolution	600 x 600 dpi
Scan Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Monthly Duty Cycle	30, 000 pages
Input Capacity	150 sheets
ADF Capacity	15 sheets
Functions	Print, Copy, Scan, Fax
Standard Memory	128 MB
Paper Handling Output	100 sheets
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Duplex Printing	Manual
Paper Capacity	150 sheets
Fax Transmission Speed	3 seconds per page
Print Technology	Laser
Media Sizes Supported	A4, Letter, Legal, Executive
First Page Out Time	27 seconds (color)
Maximum Paper Size	Legal (8.5 in x 14 in)
Operating System Compatibility	Windows, Mac OS
