Loading Print Media 211
17
Loading Print Media
Loading print media properly helps prevent jams and ensures trouble-free printing.
Before loading print media, identify the recommended print side of the print media. This information is usually on
the print media package.
NOTE: The images used in this manual are those of the Dell™ C1765nfw Color Multifunction Printer unless otherwise mentioned.
NOTE: After loading paper in the feeder, specify the same paper type on the operator panel.
Capacity
Multipurpose Feeder (MPF) can hold:
• 150 sheets of standard paper
• 16.2 mm (0.64 inches) of thick paper
• One sheet of coated paper
• 16.2 mm (0.64 inches) of post cards
• Five envelopes
• 16.2 mm (0.64 inches) of labels
Priority Sheet Inserter (PSI) can hold:
• 10 sheets of standard paper or one sheet of other paper
Print Media Dimensions
Both MPF and PSI accept print media within the following dimensions:
• Width — 76.2 mm (3.00 inches) to 215.9 mm (8.50 inches)
• Length — 127.0 mm (5.00 inches) to 355.6 mm (14.00 inches)
Loading Print Media in the Multipurpose Feeder (MPF)
NOTE: Use only laser print media. Do not use ink jet paper in this printer.
1 Open the front cover.

Dell C1765nf Color Laser Specifications

General

Print Resolution	600 x 600 dpi
Scan Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Monthly Duty Cycle	30, 000 pages
Input Capacity	150 sheets
ADF Capacity	15 sheets
Functions	Print, Copy, Scan, Fax
Standard Memory	128 MB
Paper Handling Output	100 sheets
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Duplex Printing	Manual
Paper Capacity	150 sheets
Fax Transmission Speed	3 seconds per page
Print Technology	Laser
Media Sizes Supported	A4, Letter, Legal, Executive
First Page Out Time	27 seconds (color)
Maximum Paper Size	Legal (8.5 in x 14 in)
Operating System Compatibility	Windows, Mac OS
