Dell C1765nf Color Laser User Manual

66 Installing Printer Drivers on Computers Running Windows
®
5 Click Finish to exit the wizard when the Ready to Print! screen appears. If necessary, click Print Test Page to print
a test page.
Personal Installation
A personal printer is a printer attached to your computer or a print server using a USB. If your printer is attached to
a network and not your computer, see "Network Connection Setup" on page 68.
For installing XML Paper Specification (XPS) printer driver
NOTE: Download and install the XPS printer driver at support.dell.com.
NOTE: The XPS driver is supported on the following operating systems: Windows Vista, Windows Vista 64-bit Edition, Windows
7, Windows 7 64-bit Edition, Windows 8, Windows 8 64-bit Edition, Windows Server 2008, Windows Server 2008 64-bit Edition,
Windows Server 2008 R2, and Windows Server 2012.
Windows Vista or Windows Vista 64-bit Edition
1 Extract the zip file you downloaded to your desired location.
2 Click Start → Control Panel → Hardware and Sound → Printers .
3 Click Add a printer .
4 Click Add a local printer .
5 Select the port connected to this product, and then click Next .
6 Click Have Disk to display the Install From Disk dialog box.
7 Click Browse , and then select the extracted folder in step 1.
8 Click OK .
9 Select your printer name and click Next .
10 To change the printer name, enter the printer name in the Printer name box. To use this printer as the default
printer, select the check box displayed under the
Printer name . Click Next .
Installation starts.
If the
User Account Control dialog box appears, click Continue .
NOTE: If you are an administrator on the computer, click Continue; otherwise, contact your administrator to continue the
desired action.
11 As the driver installation is completed, click Print a test page to print a test page.
12 Click Finish .
Windows Server 2008 or Windows Server 2008 64-bit Edition
NOTE: You must log in as an administrator.
1 Extract the zip file you downloaded to your desired location.
2 Click Start → Control Panel → Hardware and Sound → Printers .
3 Click Add a printer .
4 Click Add a local printer .
5 Select the port connected to this product, and then click Next .
6 Click Have Disk to display the Install From Disk dialog box.
7 Click Browse , and then select the extracted folder in step 1.
8 Click OK .
9 Select your printer name and click Next .

Dell C1765nf Color Laser Specifications

General

Print Resolution	600 x 600 dpi
Scan Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Monthly Duty Cycle	30, 000 pages
Input Capacity	150 sheets
ADF Capacity	15 sheets
Functions	Print, Copy, Scan, Fax
Standard Memory	128 MB
Paper Handling Output	100 sheets
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Duplex Printing	Manual
Paper Capacity	150 sheets
Fax Transmission Speed	3 seconds per page
Print Technology	Laser
Media Sizes Supported	A4, Letter, Legal, Executive
First Page Out Time	27 seconds (color)
Maximum Paper Size	Legal (8.5 in x 14 in)
Operating System Compatibility	Windows, Mac OS
