Dell PowerEdge C6220 II Hardware Owner's Manual

Using the System Setup Program | 119
of BMC LAN port as 10.106.42.120)
Table 2-1. The D4 Token Table
Token
Setup option
Description
002D
Embedded NIC1
Enables the system’s primary embedded network
interface controller (full-function), including its
PXE boot-ROM.
002E
Embedded NIC1
Disables the system’s primary embedded network
interface controller.
0051
N/A
For the next system boot, set the IPL priority to: USB
storage, hard disk, CD/DVD-
ROM, RAID, Network (if
the devices are available)
0052
N/A
For the next system boot, set the IPL priority to: hard
disk then option ROMs (if the devices are available)
0053
N/A
For the next system boot, set the IPL priority to:
Network, hard disk, RAID,USB storage, CD/DVD-
ROM (if the devices are available)
0054
N/A
For the next system boot, set the IPL priority to:
CD/DVD-ROM, USB Storage, hard disk, RAID,
Network (if the devices are available)
005C
N/A
Enables the BIOS remote update on the next reboot,
to search for an operating-system initiated
BIOS update image.
005D
N/A
Disables the BIOS remote update on the next reboot,
to search for an operating-system initiated
BIOS update image.
006E
Embedded NIC1
Enable the system’s primary embedded network
interface controller, but don’t enable the NIC’s
associated PXE or RPL boot-ROM.
0087
Video
Enumeration
The onboard video controller is used for boot-time
messages.

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
