Installing the Interposer Extender for 2U Node Tray
1 Place the interposer-extender tray into the system board. See Figure 3-
16.
2 Replace the screws that secure the interposer extender tray for 2U node
to the system board. See Figure 3-16.
3 Replace the interposer extender for 2U node. See Figure 3-15.
4 Connect all the cables to the interposer extender for 2U node. See
Figure 5-11.
5 Replace the system-board assembly. See "Installing a System-Board
Assembly" on page 164.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
